Product Name |
40A MPPT Solar Charge Controller |
|
Model Number |
2440N |
|
Type |
MPPT |
|
Application |
Charger Controller, Solar Working Station, Solar System Controller |
|
Work Time (h) |
24 Hours |
|
Max PV Power |
600w/12v;1200w/24v |
|
Max PV Voltage |
100voc |
|
Certificate |
CE; RoHS |
|
Warranty |
2 year |
|
Controller Dimension |
218*150*65mm |
|
Communication Port |
RS485 |
|
Working Temperature |
-35°C ~ +45°C |
|
Operating Altitude |
<3000meters |
|
External Temperature Sensor |
Yes |
|
Net Weight |
2.0kg |
|
IP Protection |
IP32 |
High Quality & Functions
- Compensates battery charge voltages with use of temperature sensor
- Over rating electronic components to minimize the power loss from heating
- Full charge power output up to 45ºC
- Aluminum casing for better cooling and charge function in high temperature
- Tempered glass cover, touch screen button for better operation
- Polyurethane filled inside for better cooling and waterproof
- LCD screen display
- Lead-acid AGM/GEL/Flooded & Lithium batteries supportable
